Introduction

Welcome to the bluz docs!

This is the place to get you started with your new hardware. We have divided up the documents into a few sections depending on what you are looking for.

As always, there are plently of places to find help beyond the documentation.

So, what is bluz?

Bluz is a development kit that acts like an Arduino, but has Bluetooth LE (BLE) communication built-in. With this BLE connection, the device can talk to the Particle cloud, a service that allows you to access your hardware anywhere in the world through a REST API. You can call functions, get variables, publish or subscribe to events, trigger webhooks, and even program it over the air through a Web IDE.

Bluz is perfect for wireless applications that require long battery life. Becuase it uses BLE, bluz can last for months or years on a coin cell battery, all while staying connected to the cloud and fully accessible.

Bluz is programmed with Wiring, the same language used in Arduino, so it will feel familiar to many compatible development kits.

One more thing...

There is one concept we felt deserved enough attention to put on the front page. Many of you know the classic blank sketch for all Arduino boards.

void setup() {
    //setup code
}

void loop() {
    //code to continuously run
}

With bluz, there is one addition to this pattern that we want you to learn. You see, bluz is a little different as it is geared towards low power.

void setup() {
    //setup code
}

void loop() {
    System.sleep(SLEEP_MODE_CPU);

    //non-blocking code goes here
}

This pattern will keep your bluz board in the lowest possible power consumption state at all times, while staying connected and available. It works by shutting off the CPU and high frequency clock, except to handle BLE events or system interrupts. In this state, the system will still wake up every 100mSeconds, driven by a timer interrupt, to perform house-keeping duties such as turning the LED on/off. This will also run the main loop() function, so even with this line of code, your loop() will run 10 times every second.

Your sketch should ultimately try to remove any blocking code from the loop() that would prevent entering this sleep mode. Code like delay() or while(waitingForEvent) { } loops will cause the CPU to stay on and more power will be consumed. Try moving necessary code into interrupts and only check flags or timing in the loop(), this will greatly increase your battery performance.

Of course, you don't HAVE to do this, you can still run your normal Arduino sketched. We just HIGHLY recommend it to provide maximum battery life for your projects.
